300Mbps 2.4Ghz Wireless Wifi Repeater Amplifier Extender
- Stock: In Stock
- Model: 1303925
$18.94
Ex Tax: $18.94
Specifications:
ÂÂ
ÂÂ
1. Item: Intelligent WIFI Signal Repeater
2. Model: WF8500
3. Color: White
4. Main Chip: MTK7628
5. Speed: 300Mbps
6. Coverage Area: 175 square meters
7. Transmission Frequency Band: 2.4GHZ
8. Transmission Standard: IEEE 802.11b.g.n
9. Network Protocol: TCP/IP Protocol
10. Background Setting URL: 192.168.16.1
11. Login User Name: admin
12. Login Password: admin
13. Input Voltage: 100-240V 50/60HZ
14. USB Output Voltage: 5V-1A
15. Size: 88*58*44mm
16. Weight: 150g
17 Plug: US Plug(A plug converter according to your country will be delivered as well.)
17 Plug: US Plug(A plug converter according to your country will be delivered as well.)
ÂÂ
Features:
ÂÂ
ÂÂ
1. MTK7628 scheme, easy to use, strong compatibility
2. The expansion rate of wireless transmission speed up to 300mbps.
3. Support EEE802.11b/g/n standard
4. The wireless repeater has a dual copper dual antenna coverage area with a significant 360-degree dead-end performance.
5. Can provide better wireless performance, transmission rate and stable signal network Let WIFI expand and cover more widely Received signal is highly sensitive and sensitive Equipment connects the signal and surfs the Internet to watch the video and doesn't get stuck.
6. Simple and convenient to use It only requires simple operation of the phone. AP mode + relay mode + customer mode + charging, one machine for multiple purposes.
Instructions:
ÂÂ
ÂÂ
1.AP mode:
Connect a network cable to the Internet access port, the device can automatically obtain an IP address, and the WIFI signal is transmitted. WIFI name WF8500, no password (default), If you want to modify the WIFI name and add the password, you need to open the phone WIFI, search for WF8500 and connect successfully, the browser enters the background 192.168.16.1 set the AP mode, according to the prompt.
After the setting is completed (you cannot insert a network cable before setting the device. After you access the network cable, the device automatically obtains the IP address of the upper-level route. In this case, entering 192.168.16.1 cannot enter the background of the device.)
ÂÂ
2. Relay mode:
Open the mobile phone WIFI, search for WF8500 and connect successfully, enter the browser, enter 192.168.16.1, user name admin password admin, then click on the relay mode, will automatically pop up a dialog box,
It contains the WIFI name that has been found, selects the WIFI name that needs to be relayed, enters the WIFI password that needs to be relayed, and saves it. After the completion, the new WIFI name is the extended router name + PLUS, and the password.
It is still the password of the extended router, and the password is unchanged.
ÂÂ
3. Relay mode: wireless to wired customer mode
After the trunk mode is set, after the second function is set, the device can directly access a network cable to enter the client mode or access other network devices, such as Internet TV switches, to access the Internet.
ÂÂ
4. Support WPS function Just press the WPS button, a key to set up the connection to achieve this feature connection requires the superior extension router must support WPS function at the same time
Note: The AP mode and relay mode cannot be used at the same time. Only one mode can be selected.
ÂÂ
Enter the method in the background, the mobile phone or computer opens WIFI, searches for the device WF8500, the connection is successful, open the browser, enter 192.168.16.1, and enter password.
ÂÂ
5. Reset
Restore the factory setting method: Press and hold the side reset button for 3-5 seconds to release, the indicator light will be off once and restart.
Package Included:
ÂÂ
ÂÂ
1 * Wireless Repeater
1 * RJ-45 Networking Cable
1 * User Manual
