Features:

CPU: NVT8304SE

Fully DVB-S/S2 compliant.

MPEG-2/MPEG-4(H.264)SD/HD decoding(MP@ML/HL)

DiSEqC1.0/1.1/1.2, USALS, Unicable and MDU supported.

Internet Application supported, Youtbe, Internet Radio, IPTV and OTT.

USB PVR and Timeshift supported.

Multimedia(MKV/AV/MPG/MOV/JPG/PNG/MP3 and so on)supported.

USB WIFI dongle supported(Ralink5370/7610)

3G dongle supported(Huawei E303s/E77/E173/E153/E3131/E1750/E1752C)

Easy and fast software upgrade through USB portm by HTTP serve or FTP serve, by OTA

More than 5000 channels memory space.

8 Favorire channel groups.

7 days Electronic Program Guide(EPG)

Channel search by automatic, manual and fastest blind scan.

Teletext output with both VBI and OSD

Multi-language subtitle output supported.

Multi-language and 32 bits true color on screen display(OSD)supported.

Aspect ratio 4:3 and 16:9

Signal level &quality indicator

Parental Lock/Channel Lock

Database backup to USB disk and restore from it at any time.

Ã‚Â

Specifications:
Ã‚Â

1. Processor

(1)Flash Memory:4Mb

(2)DDR3: 512Mb

2. DVB-S/S2 Tuner

(1)Input Frequency: 950~2150MHz

(2)Loop out Frequency: 950~2150MHz

(3)Input Level: -80~-20dBm

(4)Input Impedence: 75ÃŽÂ©

3. Channel Decoding

(1)Demodulation: QPSK, 8PSK

(2)FEC Mode: DVB-S:1/2, 2/3, 3/4, 5/6, 7/8

DVB-S2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10(QPSK)3/5, 2/3, 3/4, 5/6, 8/9, 9/10(8PSK)

(3)Symbol Rate: DVB-S:2.0~45MS/s

(4)Demodulation: QPSK, 8PSK, DVB-S2:10-30Mb/s(QPSK), 10-31Mb/s(8PSK)

4. Demultiplexer

(1)Standard: ISO/IEC 13818-1

(2)Input Max Bit Stream Rate: 100Mbps(Serial)/12.5MBps(Parallel)

5. Video Decording

(1)Standard: ISO/IEC 13818-2, MPEG-2 MP@ML, MPEG-4 AVC (MPL4.1)

(2)Aspect Ratio: 4:3, 16:9

(3)Video Format: PAL-B/NTSC-M/PAL-N/PAL-M

(4)Video Resolution: 1080P, 1080I, 720P, 480P/576P, 480I/576I SD compatible

6. Audio Decoding

(1)Standard: ISO/IEC 13818-3

(2)Decoding: MPEG-1 Layer Ã¢â€¦Â and Ã¢â€¦Â¡, MPEG-2, MPEG-4 AAC

(3)Output Mode: LPCM, RAW

(4)Samping Frequency: 32, 44.1, 48KHz

(5)Volume Level: 24 Levels

7. AV Output

(1)Video de-emphasis: CCIR REC.405-1, 625LINES

(2)Video Bandwidth: 5.5MHz

(4)Video Output Level: 1.0Vp-p

(5)Audio Output: Stereo

(6)Audio Output Frequency:20Hz~20KHz

(7)Audio Output Impedence: low

(8)Audio Output Level: A 1.0VrmsÃ‚Â±2dB into 10K

Package Included:
Ã‚Â

1 x DVB-S2 TV Receiver

1 x Remote Control

1 x User Manual

1 x Adapter
