1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve

1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
1/2" 3/4" 1" Motorized Electric Brass 3 Way Ball Valves Female 3 Wire AC 220V Full Port T Type Valve
  • Stock: In Stock
  • Model: 1288269
$31.40
Ex Tax: $31.40

Available Options







Specification:
Valve Type: Three Way Ball Valve
Body Material: Brass
Seal Material: PTFE
Connector Type: G Thread Female
Nominal Pressure: 1.6MPa (PN16)
Fluid Temperature: 2~94℃
Environment Temperature: 0~60℃
Voltage: AC 220V
Wire Control: 3 Wire
Power Consumption: 6W (Only use electricity during opening or closing.)
Open/Close Time: 5~15s
Bore Type: Full Port
Enclosure Rating: IP65
Size: 1/2"(DN15), 3/4"(DN20), 1"(DN25), 1-1/4"(DN32)

Features:
- Brass for corrosion resistance, ductility at high temperatures, and low magnetic permeability.
- Three Way female threaded ends for connecting to three male threaded ends.
- Will fully open or close valve in 5~15 seconds, once in position, it automatically stops using energy.
- Save energy, reduces likelihood of overheating, long service life.

Package Included:
1 x Motorized Brass Three Way Ball Valve
